MACH VS-2 SP

The MACH VS-2 SP is the larger "super precision" turret mill, with an ISO 40 spindle, a 1500mm table, 1000mm of X travel and powered rise and fall on the knee. Like the VS-1 SP it has the gloss black livery and polished aluminium head.

It has a dovetail X-axis with box Y and Z slides, Turcite B on the ways and gibs, a hardened and ground table and T-slots, nickel-coated lead screws, and an EVS Yaskawa spindle inverter that gives infinitely variable speeds up to 4,200rpm (5hp).

Its accuracy is second to none for a turret mill: for example, spindle taper run-out of 0.003mm against 0.005mm on standard machines.

Highlights

• Power rise and fall positioning on the knee
• Hand-scraped, hardened and ground slideways
• Turcite B on the ways, slideways and gibs
• Hardened and ground table top and T-slots
• Nickel-coated lead screws
• EVS Yaskawa spindle inverter and motor, infinitely variable speed
• 2-axis Newall DRO
• Power feed on the X-axis
• Low-voltage LED lighting
• Coolant equipment
• Stand-on composite base splash tray
• Spindle taper run-out: 0.003mm (standard machines 0.005mm)
• Y-axis travel parallelism over 300mm: 0.015mm (standard 0.03mm)
• X-axis parallelism over 500mm: 0.02mm (standard 0.03mm)
• Knee travel to table top: 0.01mm (standard 0.02mm)
• Spindle sweep to table over 300mm: 0.015mm (standard 0.02mm)
• Ram movement parallel to table: 0.015mm (standard 0.02mm)
