Specifications
- Centre Height
- 171 mm (6.73")
- Swing Over Bed
- 342 mm (13.46")
- Swing Over Cross Slide
- 209 mm (8.25")
- Distance Between Centres
- 750 mm (30")
- Bed Width
- 230 mm (9")
- Spindle Nose
- D1-4 x MT No. 5
- Spindle Bore
- 40 mm (1.57")
- Spindle Speeds
- 16 steps via 8 ranges and a 2-speed motor
- Speed Range
- 150-1,305 RPM
- Second Speed Range
- 2,100-2,570 RPM
- Carriage Length
- 400 mm (15.75")
- Cross Slide Travel
- 180 mm (7")
- Compound Slide Travel
- 100 mm (4")
- Whitworth Threads
- 45 / 2-72 TPI
- Metric Threads
- 39 / 0.2-14 mm
- DP Threads
- 21 / 8-44 DP
- MP Threads
- 18 / 0.3-3.5 MP
- Longitudinal Feeds
- 0.05-1.7 mm/rev (0.002"-0.067")
- Cross Feeds
- 0.025-0.85 mm/rev (0.001"-0.034")
- Tailstock Quill Diameter
- 50 mm (2")
- Tailstock Quill Travel
- 112 mm (4.5")
- Quill Taper
- MT No. 3
- Main Motor
- 2.2 kW (5 HP) AC
- Coolant Pump
- 0.25 HP
- Overall Dimensions (L x W x H)
- 2270 x 965 x 1900 mm
- Machine Weight
- 1200 kg
